Product Overview
The 52Amp 600V 2x4 Position Terminal Block Distribution Module. OONO D-1664GP is a Screw product. It features 52 amp 600v 2x4 position screw terminal block distribution module..
Key Features
- 52 Amp 600V 2x4 position screw terminal block distribution module.
- Rated current 52 Amp(per pole total input or output), Maximum voltage 600V.
- Screw terminal blocks, Pitch 10.16mm/0.4", Wire range 20AWG ~ 6AWG / 10mm square. Rated current 52 Amp. Strip length 10mm. Screws - M4,steel, Cr3+ Zn plated. Pin header and Cage - Brass.
- UL CE CQC certified terminal blocks, FR-4 glass fiber PCB. Mounting base: PC (Polycarbonate plastic). Screw: 304 stainless steel.
Why Choose the 52Amp 600V 2x4 Position Terminal Block Distribution Module. OONO D-1664GP
The 52Amp 600V 2x4 Position Terminal Block Distribution Module. OONO D-1664GP offers 52 amp 600v 2x4 position screw terminal block and rated current 52 amp(per pole total input or. These features make the 52Amp 600V 2x4 Position Terminal Block Distribution Module. OONO D-1664GP a strong option in the Screw category.
Best For
The 52Amp 600V 2x4 Position Terminal Block Distribution Module. OONO D-1664GP is best suited for everyday screw needs.
Quick Summary
The 52Amp 600V 2x4 Position Terminal Block Distribution Module. OONO D-1664GP is a Screw product by OONO. Current Rating: 52 Amps. Item Pitch: 10.16 Millimeters. Gauge: 0.01. Connector Type: Screw. Number Of Contacts: 8. Price: $28.05.
Product Specifications
| Specification | Details |
|---|---|
| Current Rating | 52 Amps |
| Item Pitch | 10.16 Millimeters |
| Gauge | 0.01 |
| Connector Type | Screw |
| Number Of Contacts | 8 |
| Mounting Type | Panel Mount |
| Material | Polycarbonate (PC), Stainless Steel |
| Brand | OONO |
| Voltage | 600 Volts |
| Number Of Poles | 8 |
